Digital Automatic Manifold Systems
5500D series digital automatic manifold system is designed to provide an uninteruppted gas supply with an integrated circuit board. The fully automatic manifold system monitors cylinder bank pressure electronically, controls the changover when the primary cylinder bank is depleted, and eliminates the need to manually reset the valve. Even in case of power failure, the system continues to supply gas without interruption.
Standard Construction
- 24" flexible high pressure stainless steel braided pigtails with check valve. Rigid copper pigtails are available as an option.
- For Acetylene or fuel gas model, outlet connection is mounted with dry flashback arrestor (FA30PF). As an option, hydraulic flashback arrestors are available for an additional charge
- Gentec's ultra high flow regulator series 153 & 155L
- Relief valve for protecting down-stream piping.
Automatic Changeover System
- Fully enclosed, tamper-resistant metal cabinet.
- Pressure switch control.
- LED indicators provide system status.
Pipeline
- Open-style manifold.
- Silver brazing on piping joints for maximum leak prevention.
- System is designed to accomodate future expansion needs.
- Unique changeover valve provides continuous supply of gas between primary and reserve banks
- Pressure switch port available.
- Easy installation.
- Wall or floor mount available.
